Name: UBC-220 RISC Compact Box
Brand: Advantech
Availability: InStock

UBC-220 RISC Compact Box

Freescale i.MX6 RISC Compact Box

Features:

Freescale ARM Cortex-A9 i.MX6 Dual Lite 1 GHz high performance processor
Onboard DDR3 1 GB, 4 GB eMMC Flash
Supports OpenGL ES 2.0 and OpenVG 1.1 hardware accelerators, full HD 1080p video codec
HDMI 1920x1080
Single Channel 18/24 bit LVDS
1 4-wire UART
1 USB 2.0, 1 USB OTG client
1 10/100/1000 Mbps Ethernet; 1 SD Slot
Dual mini-PCIe for WIFI/3G support
Multiple OS support in Linux/Android

Computer System
CPU	NXP ARM® Cortex®-A9 i.MX6 dual-core lite 1 GHz processor
Memory	1 GB of onboard DDR3
Storage	4 GB of eMMC Flash for OS and 4 MB of NOR Flash for Advantech’s boot loader
Display Interface	1 x HDMI ; 1 x LVDs
USB	1 x USB 2.0 Type A ; 1 x USB 2.0 OTG
Serial Ports	1 x 4-wire RS-232
Ethernet	1 x GbE LAN
Power Input	12 VDC
Dimensions (mm)	142 x 101 x 30 mm
Certifications	CE/FCC Class B

File	Size
UBC-220_DS.pdf	568.89KB	Download
