Equipped with DeviceOn/iService software for remote device management
Wide operating temperature range (-30 ~ 70 °C/-22 ~ 158 °F)
MIL-STD-810G and 5M3 certified for shock and vibration tolerance
Easily paired with TREK in-vehicle smart displays (TREK-303/306) via a single-cable connection
Part numbers:
TREK-674-LWB7A0E
TREK-674-LWB7B0E
Computer System
CPU
Intel® Atom™ E3827 (dual core, 1.75 GHz)
Memory
1 x SODIMM socket
Up to 8 GB DDR3L-1066/1333 non-ECC memory (2 GB default)
Display Interface
VGA: 1 x DB15 (up to 2560 x 1600 resolution)
1 x 18-bit LVDS (800 x 480/1024 x 768 resolution with auto-detection)
1 x Line-Out2 (for TREK-30x speakers)
2 x UART (TX/RX, TX/RX/RTS) (for touchscreen, hot keys, brightness, and light sensor control)
USB
1 x USB 3.0 Type A (front)
2 x USB 2.0 Type A (rear, with cable clip)
Serial Ports
1 x RS-485 with auto flow control
1 x 4-wire RS-232
1 x High-speed full RS-232, DB-9 (Pin 9 = ring, 12/5 V @0.5A is BOM optional via jumper setting)
Ethernet
2 x Giga LAN, with locked-type RJ45 connector
Power Input
Supports 12/24 V vehicle power, 9 ~ 32 V DC input (ISO 7637-2 and SAE J1113 compliant)
System power on/off/hibernate management (programmable ignition on/off/delay)
Supports wake-up events: wake-on-alarm (RTC), wake-on-call/SMS, and wake-on-G-sensor
System power protection (vehicle battery low voltage protection)
System monitoring and diagnostics
Dimensions (mm)
294 x 73 x 184 mm
Certifications
MIL-STD-810G and 5M3 certified for shock and vibration tolerance
